C-Frame Rubber Injection Machine (RC Series)

1. The RC series C-frame rubber injection machine adopts first-in-first-out (FIFO) method with plasticizing and injection completely separated.
2. The machine is featured with precise injection volume and minimum injection runner length; the floating-type nozzle ensures excellent temperature control.
3. The clamping unit with 3-sides-accessible C-frame structure facilitates the operation.
4. The whole RC product line is approved by CE safety standards.

RC series silicon rubber injection molding machine adopts first-in-first-out method injection unit or plastic injection unit, which is designed according to European standard with the advantages of high precision and fast speed.

Item	Unit	DKM-RC25	DKM-RC40	DKM-RC80
Injection Pressure	bar	1560	1560	1800
Injection Volume	cc	120	120	200
Clamping Force	kN	250	400	800
Mould Opening Stroke	mm	380	380	360
Distance Between Heating Plates	mm	430	430	530
Min. Mould Thickness	mm	50	50	170
Heating Plate Dimension	mm	300x400	300x400	400x400
System Pressure	bar	250	250	250
Machine Weight	ton	2.5	3	6
Machine Dim. (LxWxH)	m	1.1x1.36x2.9	1.2x1.4x3	1.5x1.95x3.28
Hydraulic Pump Power	kW	7.5	7.5	11
Heating Plate Power	kW	7	9	7.4
Total Power	kW	16	20	30
